About the Design
A concert-scale lighting environment built around five suspended hexagonal truss rings and four vertical towers, rendered as a series of pre-visualized looks. The design moves from warm, intimate gold states to full high-energy beam and aerial work — exploring how a single architectural system can carry an entire show's emotional range.
Process & Documentation
These renderings are paired with the working light plot and rig behind them. The plot drives every look shown here: ring-mounted profiles and beams, side towers, floor strobes and washes, blinders and laser, all pre-visualized before a single fixture is hung.
5
Hexagonal truss rings
64
Robe Robin iBolt
72
Chroma-Q Color Force II
60
High End Zeo wash
40
Robe Tetra2 strobe
23
Vari-Lite VL6500 wash
80
ADJ Pixie Strip
20
X-Laser Skywriter
Light plot — five hexagonal ring positions, four side towers, FOH and floor systems.
