About the Design
A two-sheet drafted light plot for Macbeth — a proscenium rig with ten electrics, a groundrow, and a full complement of side booms and front-of-house cove positions for a deep, sculptural look.
Plot & Paperwork
Sheet 1 is the onstage electrics plot; sheet 2 details the booms and FOH positions. ETC Source Four profiles and PARs, Strand Fresnelites, and Showline LED battens. The full instrument schedule — 131 fixtures with channel, type, purpose, color, gobo and focus, organized by position — is available to download below.
Sheet 1 — onstage electrics.
Sheet 2 — booms & front of house.
Instrument Schedule (PDF)131-fixture instrument schedule, exported from Vectorworks and organized by position.
Plot exported from Vectorworks (educational license watermark visible). Clean re-exports can be swapped in later.
